Thermacut T-12021 gouging nozzle replaces Hypertherm 220797

This part replaces Hypertherm 220797-UR. It's Thermacut T-12021, the gouging nozzle for 65 and 85A, and it suits Hypertherm Duramax torches on Powermax 65, 85 and 105. Pack of 5.

Parts that go with it

Up to 85A, the shield or deflector and the nozzle must be used together as a set. The electrode and swirl ring are always used together as a set.

Setup Shield or deflector Retaining cap Swirl ring
Gouging, 65/85A 220798 Gouging Shield T-12022 220854 Retaining Cap T-11423 220857 Swirl Ring T-11861

This setup uses 220842 Electrode 45–105A T-11883 (5 electrodes plus a swirl ring spring holder).

Buy it in a kit

This nozzle also comes in this kit, with the other parts it's used with.

65/85A Gouging Kit T-DMXKIT6585HG
2 × Gouging Shield, 1 × Retaining Cap, 10 × Gouging Nozzle, 1 × Swirl Ring, 5 × Electrode

View the 65/85A gouging kit
Choose your amperage and torch in our Powermax consumables guide to get the full set for this part.

Open the Powermax consumables guide

Common questions about the T-12021 nozzle

Does T-12021 replace Hypertherm 220797?
Yes. T-12021 is the Thermacut replacement for Hypertherm 220797-UR, the 65/85A gouging nozzle for Duramax torches. It comes in a pack of 5.
Which nozzle do I need?
Match the nozzle to your amperage and job. For cutting, use 220941 Nozzle 45A T-11378 at 45A, 220819 Nozzle 65A T-11377 at 65A, 220816 Nozzle 85A T-11405 at 85A and 220990 Nozzle 105A T-11840 at 105A. For gouging, use this nozzle at 65 or 85A and 220991 Gouging Nozzle 105A T-12023 at 105A. For FineCut on thin sheet, use 220930 FineCut Nozzle 45A T-11845.
Which Powermax machines does this nozzle fit?
It fits the Powermax 65, 85 and 105 with a Duramax hand or machine torch. It doesn't suit Powermax SYNC systems (they use one-piece cartridges), the original Powermax45 or the Powermax30.
Can I use T-12021 for gouging at 105A?
No. At 105A, gouging uses the 220991 Gouging Nozzle 105A T-12023 with Retaining Cap 105A T-11422 and 220994 Swirl Ring 105A T-11930. They're sold together in the 105A Gouging Kit T-DMXKIT105HG.
Alternative SKU: 220797
Alternative SKU: 220797-UR

Part Number/SKU: T-12021

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

  • Thermacut T-12021, gouging nozzle 65/85A
  • Replaces Hypertherm 220797-UR
  • Pack of 5
  • For Duramax torches on Powermax 65, 85 and 105
Part number (SKU) T-12021
Replaces Hypertherm 220797-UR
Brand Thermacut
Part type Gouging Nozzle 65/85A
Standard pack 5
Torch Hypertherm Duramax torches
Systems Hypertherm Powermax 65, 85, 105
Kits T-DMXKIT6585HG
SKU T-12021
Brand THERMACUT
Shipping Weight 0.20kg
Shipping Width 0.200m
Shipping Height 0.200m
Shipping Length 0.200m
Shipping Cubic 0.008000000m3
Unit Of Measure Pk
