Thermacut T-11842 105A shield for machine torches replaces Hypertherm 220993

This part replaces Hypertherm 220993-UR. It's Thermacut T-11842, a 105A shield for Hypertherm Duramax machine torches on the Powermax 105. Sold each.

Parts that go with it

At 105A, the shield, retaining cap and nozzle must be used together as a set. The electrode and swirl ring are always used together as a set.

SetupRetaining capNozzleSwirl ring
Shielded cutting, 105ARetaining Cap 105A T-11422
Ohmic Retaining Cap 105A T-11932		220990 Nozzle 105A T-11840220994 Swirl Ring 105A T-11930

This setup uses 220842 Electrode 45–105A T-11883 (5 electrodes plus a swirl ring spring holder).

Buy it in a kit

This shield also comes in this kit, with the other parts it's used with.

105A Machine Torch Kit T-DMXKIT105M
2 × Shield for Machine Torch 105A, 1 × Retaining Cap 105A, 10 × Nozzle 105A, 1 × Swirl Ring 105A, 5 × Electrode

View the 105A machine torch kit
Choose your amperage and torch in our Powermax consumables guide to get the full set for this part.

Open the Powermax consumables guide

Common questions about the T-11842 shield

Does T-11842 replace Hypertherm 220993?
Yes. T-11842 is the Thermacut replacement for Hypertherm 220993-UR, the 105A shield for Duramax machine torches.
Which shield do I need?
It depends on your torch, amperage and job. For cutting at 45, 65 and 85A, use 220818 Shield for Hand Torch 45/65/85A T-11406 on a hand torch or 220817 Shield for Machine Torch 45/65/85A T-11404 on a machine torch. At 105A, use 220992 Shield for Hand Torch 105A T-11841 on a hand torch or this shield on a machine torch. For gouging, use 220798 Gouging Shield 65/85/105A T-12022, and for FineCut on an ohmic table, 220948 FineCut Ohmic Shield 45A T-12014.
Which Powermax machines does this shield fit?
It fits the Powermax 105 with a Duramax machine torch. It's a 105A part, so it isn't for the Powermax 65 or 85. It doesn't suit Powermax SYNC systems (they use one-piece cartridges), the original Powermax45 or the Powermax30.
Alternative SKU: 220993
Alternative SKU: 220993-UR

Part Number/SKU: T-11842

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

  • Thermacut T-11842, 105A shield for machine torches
  • Replaces Hypertherm 220993-UR
  • Sold each
  • For Duramax machine torches on the Powermax 105
Part number (SKU) T-11842
Replaces Hypertherm 220993-UR
Brand Thermacut
Part type Shield for Machine Torch 105A
Standard pack 1
Torch Hypertherm Duramax machine torches
Systems Hypertherm Powermax 105
Kits T-DMXKIT105M
SKU T-11842
Brand THERMACUT
Shipping Weight 0.20kg
Shipping Width 0.150m
Shipping Height 0.150m
Shipping Length 0.150m
Shipping Cubic 0.003375000m3
Unit Of Measure ea

Be The First To Review This Product!

Help other National Welding and Industrial Supplies users shop smarter by writing reviews for products you have purchased.

Write a product review


Thermacut T-11842 105A shield for machine torches replaces Hypertherm 220993

This part replaces Hypertherm 220993-UR. It's Thermacut T-11842, a 105A shield for Hypertherm Duramax machine torches on the Powermax 105. Sold each.

Parts that go with it

At 105A, the shield, retaining cap and nozzle must be used together as a set. The electrode and swirl ring are always used together as a set.

SetupRetaining capNozzleSwirl ring
Shielded cutting, 105ARetaining Cap 105A T-11422
Ohmic Retaining Cap 105A T-11932		220990 Nozzle 105A T-11840220994 Swirl Ring 105A T-11930

This setup uses 220842 Electrode 45–105A T-11883 (5 electrodes plus a swirl ring spring holder).

Buy it in a kit

This shield also comes in this kit, with the other parts it's used with.

105A Machine Torch Kit T-DMXKIT105M
2 × Shield for Machine Torch 105A, 1 × Retaining Cap 105A, 10 × Nozzle 105A, 1 × Swirl Ring 105A, 5 × Electrode

View the 105A machine torch kit
Choose your amperage and torch in our Powermax consumables guide to get the full set for this part.

Open the Powermax consumables guide

Common questions about the T-11842 shield

Does T-11842 replace Hypertherm 220993?
Yes. T-11842 is the Thermacut replacement for Hypertherm 220993-UR, the 105A shield for Duramax machine torches.
Which shield do I need?
It depends on your torch, amperage and job. For cutting at 45, 65 and 85A, use 220818 Shield for Hand Torch 45/65/85A T-11406 on a hand torch or 220817 Shield for Machine Torch 45/65/85A T-11404 on a machine torch. At 105A, use 220992 Shield for Hand Torch 105A T-11841 on a hand torch or this shield on a machine torch. For gouging, use 220798 Gouging Shield 65/85/105A T-12022, and for FineCut on an ohmic table, 220948 FineCut Ohmic Shield 45A T-12014.
Which Powermax machines does this shield fit?
It fits the Powermax 105 with a Duramax machine torch. It's a 105A part, so it isn't for the Powermax 65 or 85. It doesn't suit Powermax SYNC systems (they use one-piece cartridges), the original Powermax45 or the Powermax30.
  • Thermacut T-11842, 105A shield for machine torches
  • Replaces Hypertherm 220993-UR
  • Sold each
  • For Duramax machine torches on the Powermax 105
Part number (SKU) T-11842
Replaces Hypertherm 220993-UR
Brand Thermacut
Part type Shield for Machine Torch 105A
Standard pack 1
Torch Hypertherm Duramax machine torches
Systems Hypertherm Powermax 105
Kits T-DMXKIT105M
SKU T-11842
Brand THERMACUT
Shipping Weight 0.20kg
Shipping Width 0.150m
Shipping Height 0.150m
Shipping Length 0.150m
Shipping Cubic 0.003375000m3
Unit Of Measure ea

Be The First To Review This Product!

Help other National Welding and Industrial Supplies users shop smarter by writing reviews for products you have purchased.

Write a product review
