Universal Level Magnetic Contour Level #33 Weldclass KC-J1904

Multi-purpose tool for assisting in a range of pipefitting tasks, including aligning / two-holing flanges, setting angles, etc. Includes adjustable protractor dial-level, flange pins & magnetic base. Click on 'Video' to view a demonstration.

• Valuable Multi-purpose tool for assisting in a range of pipefitting tasks
•  Adjustable 360DG protractor-dial level allows use in any position
• Magnetic

Suitable applications include:

•  Aligning / Two-holing flanges
•  Setting a predetermined pitch of a string of pipe
•  Setting the angle of laterals to a precise degree
•  Trueing vertical runs

WHAT ELSE :

•  The Level has two cast-in 25-pound magnets (exerting a 50-pound pull) to securely hold the unit in place on any steel surface, including the underside of a pipe or beam.
• Both faces have deep, cast-in grooves that make the Level self-centering on the contour of the pipe.
•  Cast in magnets do not interfere with the use of the Level on non magnetic materials, such as aluminium, copper, lumber, stone or other materials requiring levelling.
•  For aligning pipe flanges (two-holing), the Level comes with a two-threaded, self aligning conical spacer and conical nut and bolt units. These are designed to fit any size bolt hole spaced between 2-1/4 in. to 8-in. centers on flanges. This permits the orientation of flange bolt holes for any size pipe.
• A cast-in table indicates rise per foot in both inches and meters.
• Two-holing is simplified with the Universal Level. Self-aligning spacer bolt units are attached in the two adjacent bolt holes at the top or bottom of the flange. With the DSL dial set at O degrees, the flange is rotated until the bubble is centered. If adjacent top or bottom holes cannot be used, two-holing can be achieved using side bolt holes. In this instance, the DSL dial is set at 90 degrees and the flange is rotated until bubble is centered. Bolt holes that are offset can be matched by setting the DSL at the desired offset angle prior to rotating the flange.

WELDCLASS is the official Australian distributor for Jackson Contour Curv-O-Mark products.

Alternative SKU: 0721-0030

Part Number/SKU: KC-J1904
