Stud Welder Drawn Arc For Ø 2-22mm Steel & Stainless Steel Welding PRO-D2200

Details

  • welding current continuously adjustable
  • welding time continuously adjustable
  • constant current regulation
  • easy operation by a very robust rotary knob with a built-in push button
  •  all functions and parameters are shown on a big display (display contrast adjustable)
  • standard welding programms pre-installed (user-specific adaptable)
    • 60 user-specific welding programms can be stored
    • welding parameter monitoring and documentation
    • recording of welding current, welding time, welding energy and arc voltage for each weld
    • recording of stud travel (lift, piston runtime, immersion depth) for each weld [only when a welding gun resp. an automatic welding head with travel measuring system is used]
    • comparison of the recorded parameters to the parameters of a reference weld (tolerances adjustable)
    • in case of variances to the reference weld a warning is displayed or the unit is locked for further welds until the release by the operator (functionality can be switched off)
    • storage of the last ten welding parameter sets
    • optional (also retrofitable): welding parameter memory for the storage of 24500 welding parameter sets (storage with date and time) with USB-interface for data transmission (welding parameter sets) to a PC
  • device lock (with pin code query) to avoid unwanted parameter adjustments\
  • weld counter
  • optional (also retrofitable): shielding gas module for welding with shielding gas for weld pool backing
  • shielding gas pre-flow time continuously adjustable (with option shielding gas module)
  • optional (also retrofitable): automatic module to connect the automatic stud feeder VBZ and an automatic welding gun
  • optional (also retrofitable): two or four gun connections
    • different adjustments for welding current and welding time
    • automatic detection of used gun
    • weld counter for each gun connection\
    • optional (also retrofitable): shielding gas module for each gun connection
  • available as accessory: adapter box PRO-SPLIT
    • enables the operation of up to four stud welding guns with different adjustment values for welding current and welding time on one unit
    • automatic detection of used gun
    • weld counter for each gun connection
    • with up to four shielding gas modules
  • suitable for through deck welding\
  • functional test without welding current for lift adjustment for welding guns and heads (lift test)
  • repeat cycle lock to avoid welding on an already welded welding element
  • intelligent self-diagnosis system (display of an error code in case of an interference/failure)
  • automatic function test after switch-on
  • temperature control as protection against destruction through excess temperature
  • automatic switch-off in case of excess temperature and phase failure
  • protection of the unit in case of a fault on welding/control line cable and solenoid
  • highest operational reliability and high power-on time through exclusive use of high-quality components
  • all functions and parameters are controlled by a microprocessor
  • lifting eyes
  • two swivel castors, two fixed castors
  • robust, powder-coated metal housing
  • interface for data exchange with higher ranked control systems (CNC)
  • stable fixing of welding cable sockets at own plug holder, prevents damage on housing caused by pulling of cable

Part Number/SKU: PRO-D2200

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

SKU PRO-D2200
Brand KCD
Shipping Weight 230.0000kg
Shipping Width 0.600m
Shipping Height 0.800m
Shipping Length 0.700m
Shipping Cubic 0.336000000m3
