Welding Helmet Crystal 2.0 Silver Optrel 1006.900

Crystal 2.0 - You won't believe your eyes

With light transmission of 31% in bright condition (protection level 2!) welders have for the first time a practically unclouded and clear view of their working environment. This in combination with the almost perfect colour spectrum of the CLT2.0 for the first time allows welders to see what is really going on in the weld pool, and with a clarity that equates to insights into a new dimension. This is why welders describe this as an enlightenment.

Application Fields

• Electrode Welding (Stick Welding, SMAW)
• MIG/MAG (GMAW)
• GMAW High melting rate process
• Flux Cored Wire Welding
• TIG Welding (GTAW)
• Plasma Arc Welding
• Micro Plasma Arc Welding
• Plasma Cutting
• Gas Welding
• Grind Mode

SPECIFICATIONS

Shade levels	inactive: shade level 2.0  active, manual: shade level 4-12
Autopilot	Automatic protection level regulation across a range from 4-12 with individual calibration option of ± 2
Power supply	Solar cells, 2 lithium batteries (CR2032)
Sensors	Three Sensors
Sensitivity	Infinitely adjustable, now with “super high” sensitivity
Weight	482 g
Switching time	bright to dark : 0.100 ms at Room temp. /  0.070 ms at 55°C  dark to bright : 0.1s to 2.0s (with dimming function)
Shape Stability	Welding mask: up to 220 °C / 428 °F Front cover lens: up to 137 °C / 279 °F
Eye protection Ultraviolet / Infrared Protection	maximum protection at any shade level
Operating temperature	-10°C to + 70°C / 14°F to 158°F



Part Number/SKU: 1006.900

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.
