Part Number

75kva

Nominal power 50%

75 KVA

Maximum welding power

100 KVA

No load output voltage

7.8 V

Maximum short circuit current

25 KA

Permanent current 100%

20 KA

Supply

400-415 V Hz

Compressed air min./max

0.1-0.8 MPa

Min.throat depth

380 mm

Max.electrode force

6280 N

Max.Throat depth

600 mm

Max.electrode force

6280 N

Water cooling

8 L/Min

Aerial noise produced

30 dB(A)

Measure condition

working stroke

welding time

welding current

working rating(weld/min.)

60 mm

380 circle

25 KA

200 N/min

Net weight

550 kg

dia arms

60 mm

dia electrode-holders

25 mm

dia electrode-cone

16 mm






Part Number/SKU: 75kva

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.

SKU 75kva
Brand Easybeat
