Professional Cordless Impact Wrench Bosh GDS 18V-1050 H

GDS 18V-1050 H PROFESSIONAL: FURTHER INFORMATION

Product Highlights
The GDS 18V-1050 H Professional is the outstanding 3/4" impact wrench with brushless motor for the most diverse fields of application. Its BITURBO Brushless technology combines corded power with cordless freedom fully maximised for ProCORE18V batteries. Whenever heavy-duty performance is needed, the new impact mechanism provides a tightening Torque of 1,050 Nm and breakaway torque of 1,700 Nm for particularly challenging working environments. The high versatility in power controlling is ensured by the 3-speed/torque settings that allow adjustments to the respective work requirements.

Equipment & Application
The main areas of GDS 18V-1050 H Professional are meal applications (M10-M24) like structural steel construction, metal assembly, pipe fitting, truck maintenance, and wood construction. It is compatible with all Bosch Professional 18 V batteries and chargers (Professional 18V System), for maximum power use ProCORE18V ≥ 5.5 Ah. Also compatible with AMPShare, the multi-brand battery alliance.

Additional Information
The GDS 18V-1050 H Professional comes with additional figures like ECP, EMP, a tool status indicator, LED light, a 3/4" tool holder with friction ring plus through hole, and a ladder clip.

Full power at its best: 3/4" high torque impact wrench with BITURBO Brushless technology



• Impressive power with cordless freedom thanks to ProCORE18V batteries and brushless motor
• High performance motor with a tightening torque of 1,050 Nm and a breakaway torque of up to 1,700 Nm
• Ideal versatility and controlled power due to 3-speed/torque settings

Technical Data

The most important data
Torque adjustment range, min./max., 1st level	0/350 Nm
Torque adjustment range, min./max., 2nd level	0/750 Nm
Torque adjustment range, min./max., 3rd level	0/1050 Nm
No-load speed*	0-800 rpm
No-load speed (1st level)*	0-800 rpm
No-load speed (2nd level)*	0-1,200 rpm
No-load speed (3rd level)*	0-1,750 rpm
Torque settings	3
Weight excl. battery*	2.9 kg
Torque, max.*	1,050 Nm
Impact rate	0-2,600 bpm
Impact rate (1st level)*	0-1,600 bpm
Impact rate (2nd level)*	0-2,400 bpm
Impact rate (3rd level)*	0-2,600 bpm
Battery voltage	18.0 V
Tool holder	3/4'' Square
Breakaway torque, max.	1,700 Nm
Packaging dimensions (width x length x height)	266 x 287 x 97 mm





Screw diameter
Screw diameter	M 14 - M 24





Total vibration values (Tightening screws and nuts of maximum permitted size)
Vibration emission value ah	13.5 m/s²
Uncertainty K	1.5 m/s²





The A-rated noise level of the power tool is typically as follows: Sound pressure level 95 dB(A); Sound power level 106 dB(A). Uncertainty K= 5 dB.



Part Number/SKU: GDS18V-1050H
